Product Details
＋
| Product Attribute | Attribute Value |
|---|---|
| Alternate Mfr Part Number | T4618500 |
| Body Style | Cylindrical |
| Connection Type | M12 3-Pin |
| Current Consumption | 200 mA (Max.) |
| Current, Switching | 200 mA |
| Frequency, Switching | 0.3 kHz |
| Housing Material | CPB |
| Indicator | LED |
| IP Rating | IP67 |
| Maximum Operating Temperature | 70 C |
| Measurement Range | 15 mm |
| Minimum Operating Temperature | -25 C |
| Mounting Type | M30 Threaded Flush |
| Operating Temperature, Maximum | 70 C |
| Operating Temperature, Minimum | -25 C |
| Output | PNP |
| Primary Type | Inductive Proximity Sensors |
| Series | |
| Shielding | Shielded |
| Supply Voltage | 30 VDC |
| Termination | Wired Connector |
Overview
10 to 30 VDC , 300 Hz Frequency Range, Inductive Sensors
300 Hz frequency range
